| V | Capacity | CCA (-18℃) | Maximum dimensions/mm | Reference weight | ||||||
| Overall Dimensions | ||||||||||
| Type | 20hr Ah | RC min | L | W | H | TH | Mass | |||
| L | W | H | TH | Kg | ||||||
| 6CQW100 | 12 | 100 | 182 | 440 | 409 | 175 | 209 | 245 | 26.5 | |
| 6CQA165 | 12 | 165 | 326 | 600 | 508 | 222 | 213 | 250 | 27.3 | |
| 6CQA195 | 12 | 195 | 397 | 650 | 508 | 222 | 213 | 250 | 30.6 | |
| 6CQA240 | 12 | 240 | 505 | 820 | 517 | 274 | 215 | 255 | 41.5 | |
| 6CQW200 | 12 | 200 | 409 | 680 | 517 | 269 | 216 | 255 | 51.3 | |
| 6CQW220 | 12 | 220 | 457 | 680 | 517 | 269 | 216 | 255 | 54.7 | |
| 6CQW240 | 12 | 240 | 505 | 720 | 517 | 269 | 216 | 255 | 58.5 | |
| Note: Except for 6CQW model, which is the weight with ¶liquid, the rest are dry weight | ||||||||||
